Flutter Custom Painter &Circular Wave Animation

My Experiments with Flutter animations

Welcome back to my Flutter animation series. Where I show you my experiments with Flutter animations. In the previous blog, we saw how to animate background color using Tween animation. Today we will see how to create some amazing UI using CustomPainter and to animate it. So, Grab a cup of coffee and let’s convert some coffee into code. ☕ => {}

We will be creating *circular wave animation but first, let’s see how we can create a circle using CustomPaint. Add CustomPaint widget to your widget tree, it takes a size and a painter. Painter is a simple class that extends CutsomPainter and implement two methods, `paint(Canvas, Size) *andshouldRepaint(CustomPainter oldDelegate)`. The paint method provides us with the canvas which let us draw anything on canvas. We can draw a circle using the *drawCircle()* method. Here is a full code.

**import **'package:flutter/material.dart';

class CircleRoute extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: CustomPaint(
        size: Size(double.infinity, double.infinity),
        painter: CirclePainter(),
      ),
    );
  }
}

class CirclePainter extends CustomPainter {
  var wavePaint = Paint()
    ..color = Colors.black
    ..style = PaintingStyle.stroke
    ..strokeWidth = 2.0
    ..isAntiAlias = true;

@override
  void paint(Canvas canvas, Size size) {
    double centerX = size.width / 2.0;
    double centerY = size.height / 2.0;
    canvas.drawCircle(Offset(centerX, centerY), 100.0, wavePaint);
  }

@override
  bool shouldRepaint(CirclePainter oldDelegate) {
    return false;
  }
}

And here is the result…

Well, That’s interesting. Let’s see if we can create multiple concentric circles. To create multiple concentric circles we will define the currentRadius and maxRadius. All the circles will be drawn from the currentRadius to maxRadius with the margin of waveGap. Let’s see the code.

@override
**void **paint(Canvas canvas, Size size) {
  double centerX = size.width / 2.0;
  double centerY = size.height / 2.0;
  double maxRadius = hypot(centerX, centerY);
  double waveGap = 10.0;
  double currentRadius = 0;

  **while **(currentRadius < maxRadius) {
    canvas.drawCircle(Offset(centerX, centerY), currentRadius, wavePaint);
    currentRadius += waveGap;
  }
}

double hypot(double x, double y) {
  **return **math.sqrt(x * x + y * y);
}

With just a few lines we get our stupid yet beautiful UI :)

Now, Let’s see how we can animate these circles and make wave animation. For this, we need to animate our *currentRadius*. We can achieve this using tween animation which will begin at0 and end at waveGap.

Animation<double> _animation;

_animation = Tween(begin: 0.0, end: waveGap).animate(controller)
  ..addListener(() {
    setState(() {
      waveRadius = _animation.value;
    });
  });

We need to define our AnimationController and set it in an infinite loop like this.

AnimationController controller;

controller = AnimationController(
    duration: Duration(milliseconds: 1500), vsync: this);

controller.forward();

controller.addStatusListener((status) {
  if (status == AnimationStatus.completed) {
    controller.reset();
  } else if (status == AnimationStatus.dismissed) {
    controller.forward();
  }
});

In the end, we will set our currentRadius equals to waveRadius . Here is the final code.

import 'dart:math' as math;

import 'package:flutter/material.dart';

void main() => runApp(MyApp());

class MyApp extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: 'Wave Animation',
      debugShowCheckedModeBanner: false,
      theme: ThemeData(
        primarySwatch: Colors.blue,
      ),
      home: CircleWaveRoute(),
    );
  }
}

class CircleWaveRoute extends StatefulWidget {
  @override
  _CircleWaveRouteState createState() => _CircleWaveRouteState();
}

class _CircleWaveRouteState extends State<CircleWaveRoute>
    with SingleTickerProviderStateMixin {
  double waveRadius = 0.0;
  double waveGap = 10.0;
  Animation<double> _animation;
  AnimationController controller;

  @override
  void initState() {
    super.initState();
    controller = AnimationController(
        duration: Duration(milliseconds: 1500), vsync: this);

    controller.forward();

    controller.addStatusListener((status) {
      if (status == AnimationStatus.completed) {
        controller.reset();
      } else if (status == AnimationStatus.dismissed) {
        controller.forward();
      }
    });
  }

  @override
  Widget build(BuildContext context) {
    _animation = Tween(begin: 0.0, end: waveGap).animate(controller)
      ..addListener(() {
        setState(() {
          waveRadius = _animation.value;
        });
      });

    return Scaffold(
      backgroundColor: Colors.white,
      body: CustomPaint(
        size: Size(double.infinity, double.infinity),
        painter: CircleWavePainter(waveRadius),
      ),
    );
  }

  @override
  void dispose() {
    controller.dispose();
    super.dispose();
  }
}

class CircleWavePainter extends CustomPainter {
  final double waveRadius;
  var wavePaint;
  CircleWavePainter(this.waveRadius) {
    wavePaint = Paint()
      ..color = Colors.black
      ..style = PaintingStyle.stroke
      ..strokeWidth = 2.0
      ..isAntiAlias = true;
  }
  @override
  void paint(Canvas canvas, Size size) {
    double centerX = size.width / 2.0;
    double centerY = size.height / 2.0;
    double maxRadius = hypot(centerX, centerY);

    var currentRadius = waveRadius;
    while (currentRadius < maxRadius) {
      canvas.drawCircle(Offset(centerX, centerY), currentRadius, wavePaint);
      currentRadius += 10.0;
    }
  }

  @override
  bool shouldRepaint(CircleWavePainter oldDelegate) {
    return oldDelegate.waveRadius != waveRadius;
  }

  double hypot(double x, double y) {
    return math.sqrt(x * x + y * y);
  }
}

And here is our final animation. EUREKA!!!
